Lewmar Ocean Hatch – Size 60 Flat Base – 502 x 502mm Cut Out – CE Approved (170134)

Sale!
Lewmar Ocean Hatch - Size 60 Flat Base - 502 x 502mm Cut Out - CE Approved (170134)
Lewmar Ocean Hatch - Size 60 Flat Base - 502 x 502mm Cut Out - CE Approved (170134) - Image 2
Lewmar Ocean Hatch - Size 60 Flat Base - 502 x 502mm Cut Out - CE Approved (170134) - Image 3

Original price was: $2,129.00.Current price is: $1,836.00.

Lewmar Ocean Hatch - Size 60 Flat Base - 502 x 502mm - 39660050 (170134)

Lewmar Ocean Hatch - Size 60 Flat Base

502 x 502mm - 39660050 (170134)

With its classic style, the Lewmar Ocean Hatch is fitted to thousands of boats around the world. Its rugged construction provides the ultimate protection against the elements, whatever conditions you might face.

  • All sizes suitable for CE Area 2 (Deck, Coachroof, Cockpit and Transom)
  • Friction levers hold the lid open in any position up to 95°
  • Anodised aluminium frame for corrosion resistance
  • CE Approved
Lower Frame (mm)
Acrylic Colour
Hatch Weight (kg)
Acrylic Window Thickness (mm)
Flat Base
Smoke Grey
8
12

Length X (mm)
Width Y (mm)
Height Z (mm)
Radii R (mm)
Hinge Length HX (mm)
Hinge Width HY (mm)
Cut-Out Length (Flat/Flange) X1 (mm)
Cut-Out Width (Flat/Flange) Y1 (mm)
Cut-Out Radii (Flat/Flange) R1 (mm)
574
574
43
76
4
367
502
502
40





Weight 9 kg
Dimensions 640 × 60 × 9 cm
